TNGEL® Aerogel coating is a kind of viscous slurry thermal insulation material. The coating is compounded by main material silica aerogel powder and various inorganic fillers, as well as some special adhesives.
Product Description
TNGEL® Aerogel coating is a kind of viscous slurry thermal insulation material. The coating is compounded by main material silica aerogel powder and various inorganic fillers, as well as some special adhesives. It's an energy-saving and environmentally friendly thermal insulation coating with the characteristics of heat insulation, oil resistance, acid and alkali resistance, low density, easy construction, etc.
Outstanding thermal insulation to reduce heat loss in walls, roofs, facades, and industrial equipment
Lightweight and low-density material for easy application and minimal structural impact
Resistant to oil, acids, alkalis, and harsh environmental conditions
Eco-friendly and energy-saving solution for sustainable projects
Durable and reliable for high-temperature, cryogenic, and fireproofing applications
| Product Model | TNGEL-CT150 |
| Dry density（kg/m³） | 250-300 |
| Wet density（kg/m³） | 650-750 |
| Thermal conductivity (25°C) W/(m·k) | 0.032-0.035 |
| Maximum application temperature (°C) | 150 |
| Operating temperature (°C) | 10-100 (hot construction possible) |
| Construction method | Scrape or Spray |
| Combustion performance | B1 |
| Color | White |
| Single coating thickness | 1-3 mm |
| Drying time | 3mm thickness under normal temperature conditions: surface drying ≤24h, actual drying ≤48h; Under high temperature conditions, surface drying and actual drying time will be reduced depending on the temperature. |
| Thermal Conductivity (25°C) W/(m·k) | Bulk Density (kg/m³) | Fire Rating | Maximum Operating Temperature(℃) |
|
0.032-0.035 |
250-300 650-750 |
B1 | 150 |
TNGEL® Aerogel Coating is a high-performance viscous slurry designed for advanced thermal insulation. Made from premium silica aerogel powder, inorganic fillers, and specialized adhesives, this Aerogel Insulation Coating provides exceptional heat resistance, chemical resistance, and durability. Lightweight and environmentally friendly, TNGEL® Aerogel Coating helps save energy while offering easy application for various industrial, construction, and aerospace projects.
● Building Insulation Use
● Cold Chain & Cryogenic Systems
● Aerospace & Automotive
● Fireproofing Applications-Structural Components and Safety Equipment
● Industrial Equipment
● Temperatures and Corrosion Protection
● Battery Packs and Electronic Devices
● Reduces heat loss
● Enhances thermal efficiency in walls, roofs, and facades
● Reduces heat loss in furnaces, reactors, and pipelines
● Provides insulation for LNG tanks, refrigerated storage, and transport
● Offers lightweight thermal protection for aircraft, spacecraft, and vehicles
● Improves thermal management in battery packs and electronic devices
● Protects pipelines and storage tanks from extreme temperatures and corrosion
● Enhances fire resistance in structural components and safety equipment
Yes, TNGEL® Aerogel Coating can be sprayed, brushed, or rolled depending on the surface and project requirements. Spraying ensures uniform coverage, especially on complex or large surfaces.
Aerogel provides excellent thermal insulation but can be more expensive than traditional insulation materials. Mechanical protection is needed for long-term durability. However, as a formulated Aerogel Insulation Coating, TNGEL® significantly improves toughness and adhesion.
Aerogel is widely applied as a high-efficiency Aerogel Insulation Coating in construction, industrial equipment, cold chain logistics, aerospace, automotive, battery packs, and fireproofing solutions. It effectively reduces heat transfer and saves energy.
TNGEL® Aerogel Coating offers long-lasting performance. With proper application, it can maintain its thermal insulation properties for decades while resisting moisture, chemicals, and high temperatures.
TNGEL® Aerogel Coating is a trusted Aerogel Insulation Coating solution for industries and construction projects seeking superior thermal performance. Combining ease of application, durability, and energy-saving benefits, it provides reliable insulation for demanding environments.
